Model | ZL38-47 | ||||||||
Working Voltage Range | DC:6V-24V | ||||||||
Rating Power | 6V:0-6W 12V: 0-6W / 24V: 0-6W | ||||||||
Static Flow Rate | 0-7L/min | ||||||||
Lifespan | Continuous operation≤24hrs, under normal working surrounding >20000Hr | ||||||||
Working Environment | Liquid: From weak acid to weak base, workable on land(non-Submerged) | ||||||||
Max Noise | Under normal working status, 1M distance over test instrument <35dB | ||||||||
Max Working Temperature | Under normal surroundings, fluid medium temperature≤70℃ | ||||||||
Application | Pipeline hot water circulation, solar water heater, small fountain, aquarium, etc. | ||||||||
Size | IP Grade | Inlet | Outlet | remark | |||||
Length（mm） | Width（mm） | Height（mm） | OD（mm） | ID（mm） | OD（mm） | ID（mm） | Inlet and Outlet with filter | ||
47.2 | 38 | 119 | IP6 | / | / | / | / | ||
Remark: It’s for reference only, the one based on the customer’s endorsement demands shall prevail!
